12 Bolt EFI to Aeromotive 10 Bolt Stealth Adapter Plate
$58.00
Adapter plate that mounts a 10-bolt Aeromotive Stealth fuel pump to a 12-bolt Boyd tank. CNC 6061-T6, stainless screws included. Adds 0.625 in., so check hanger depth.
Install Level: Moderate
Fits Aeromotive Phantom 340, A1000 and Eliminator 10-bolt pumps. Not the Trifekta 18311.
Pump not included. Reuse your pump's gasket and nylon washers, not its screws.
Lead time: 2 weeks.
Finish the Build Right
Parts our crew pairs with this kit so your swap goes together right the first time.
-
Dual Phantom Aeromotive 340 Fuel Pumps
$1,062.46
Details for Dual Phantom Aeromotive 340 Fuel Pumps
-
Aeromotive 11540 Pump, 340 LPH Only
$144.95
Details for Aeromotive 11540 Pump, 340 LPH Only
This CNC machined aluminum adapter will allow you to adapt any
Aeromotive phantom 340, A1000 or Eliminator in tank pump that utilizes the
10 bolt pattern to the Boyd Welding 12 bolt pattern.
Details
- Material = CNC Machined 6061-T6
- OD= 6.00"
- ID= 3.510"
- Height = 0.500"
- Installed height without pump = 0.625"Bolt Circle A (BW EFI) = x12 @ 5.00" BCL
- Bolt Circle B (Aeromotive) = x10 10-32 @ 4.00" BCL
- Kit Includes:1) CNC Machined Adapter Plate
- 1) BW EFI FKM Viton Gasket
- 12) 10-32 1" Stainless Screws (BW Pattern)
- 10) 10-32 3/4" Stainless Screws ( Aeromotive Pattern)
NOTE: THIS ADAPTER WILL NOT WORK WITH AEROMOTIVES TRIFEKTA #18311
NOTE: You will use the pump gasket and nylon washers that were supplied with the Aeromotive pump you purchased and NOT the screws supplied with Aeromotive pumps.
Vendor: Boyd Welding
Material: CNC machined 6061-T6 aluminum
OD: 6.00 inch
ID: 3.510 inch
Height: 0.500 inch
Installed height without pump: 0.625 inch
Bolt circle A (Boyd Welding EFI): 12 holes at 5.00 inch BCL
Bolt circle B (Aeromotive): 10 holes of 10-32 at 4.00 inch BCL
Kit includes: 1 adapter plate; 1 BW EFI FKM Viton gasket; 12 of 10-32 1 inch stainless screws; 10 of 10-32 3/4 inch stainless screws
Lead time: 2 Weeks
Listed price 58.00 USD
Variant count: 8
No flange screw torque specification is published on this listing
Questions? Talk to the FFG Team
For fitment questions or build-specific guidance, the FFG team has you covered.
Email: info@fatfender.com
Call: (480) 621-6072
Adapts Aeromotive Phantom 340; A1000 and Eliminator in-tank pumps with the 10 bolt 10-32 flange on a 4.00 inch bolt circle.
Does not work with the Aeromotive Trifekta 18311.
Fitment here is defined by the tank flange pattern rather than the vehicle. The generation tags cover the Ford and Chevy trucks the Boyd tanks are built for.
