HDX Instrument Gauge System | Chevy Pickup (1964-66)

While the 1960-66 Chevy pickups are lumped together as one, the dashboard designed changed slightly. 1960-63 models require their own specific instrument cluster and what better way to show it off than a direct-fit HDX kit! Utilizing the stock bezel, or trim, this kit is a drop in upgrade, complete with a large TFT message center flanked by six analog readings in your choice of black or silver alloy. Does not fit GMC trucks.

Available with your choice of black or silver alloy gauge-face styling, each HDX system allows the user to select independent illumination colors for the gauge readings and needles, as well as the message centers. Calibration and personal settings are manipulated with the built-in, capacitive-touch buttons, or the available Bluetooth app for Apple and Android devices. Each needle hub is black nickel plated spun-aluminum to match the buttons.

All HDX instrument systems feature dead-faced indicators (turn signals, high beam, check engine, cruise control, parking brake, plus two user-definable), and a red, settable warning light for each gauge. With our central control box, installation is greatly simplified with vehicle-harness sourced signals and supplied, solid state sending units connecting cleanly to their respective terminal.

Note: Bezel not included, shown for visual/presentation purposes.
System uses OEM or reproduction style bezel.

DOES NOT FIT GMC PICKUPS

Dakota Digital part number HDX-64C-PU-K
Vendor: Dakota Digital
Series: HDX
Cluster: six analog readings around a large TFT message center; drop-in behind the stock bezel
Face styling: black alloy or silver alloy
Independent illumination color selection for gauge readings; needles and message centers
Built-in capacitive-touch buttons for calibration and personal settings
Optional Bluetooth app control for Apple and Android devices
Needle hubs: black nickel plated spun aluminum to match the buttons
Dead-faced indicators: turn signals; high beam; check engine; cruise control; parking brake plus two user-definable
Red settable warning light on every gauge
Central control box; vehicle-harness sourced signals
Solid state sending units supplied
Included: mounting hardware
Listed price 1625.00 USD
Variant count: 5
No published cluster depth; amperage draw or harness length on this listing

Fits the 1964-1966 Chevrolet C10; C20; C30; K10 and K20 Pickup as published; part number HDX-64C-PU-K.
Chevrolet application only. The same-year GMC truck is excluded by the manufacturer.
Cluster layout: six analog readings around a large TFT message center; drop-in behind the stock bezel.
Bezel not included. System uses the stock bezel or trim.
Tagged into the Chevy 1960-66 generation bucket in the store taxonomy.
