h-pipe installed on firewall

IT'S TECH TUESDAY! TODAY WE'RE DISCUSSING H-PIPES.

Jul 02, 2024Karisa Dillon

PREVIOUSLY, WE'VE COVERED THE ESSENTIAL PURPOSE OF AN H-PIPE (WHICH IS TO PREVENT COOLANT FROM DEAD-HEADING INTO YOUR HEATER CORE, ENSURING YOUR COYOTE ENGINE RECEIVES ADEQUATE COOLING TO PREVENT OVERHEATING). THIS BYPASS MECHANISM IS CRUCIAL FOR MAINTAINING OPTIMAL ENGINE TEMPERATURE. INTRODUCING OUR NEW AND IMPROVED KIT, IT'S NOW BETTER THAN EVER.

We have developed our own billet aluminum H-Pipe Bulkhead to the kits we offer: integrating the bypass directly into the billet aluminum bulkhead that you can mount right on your firewall. This innovative solution comes available in black or machined finish, reduces clamps and cleans up under the hood; enhancing both functionality and aesthetics.

We've also made another sleeker enhancement (included in the Premium Kit): utilizing a soft braided AN hose with a smaller diameter. This cleaner look eliminates the need for large rubber hoses and plastic quick disconnect fittings, streamlining the engine compartment. The transition involves replacing the existing plastic or steel adapters with specialized billet aluminum fittings on the engine, seamlessly connecting to the firewall fittings.

This approach not only simplifies the installation but also enhances the visual appeal, making it ideal for our premium builds. While this option incurs additional cost, we understand its appeal for those prioritizing a refined appearance. The OEM+ Kit includes the plastic connectors and rubber heater hose for a more budget-friendly option.

PRO TIP: Install the bulkhead VERTICAL for optimal airflow.


Whether you're searching for the Premium Kit, the OEM+ Kit or the H-Pipe Bulkhead only. kits are available on our website.


Get $50 off both H-Pipe Kits NOW-July 8th during the FFG Cool-Off Sale (discount automatically added at checkout).

KIT DETAILS:

Premium Kit Includes:

  • Billet Aluminum H-Pipe Bulkhead Adapter (Available in Raw Machined or Black Anodized Finish)
  • Billet Aluminum -08AN Connector Fitting A (Black Anodize Finish Only)
  • Billet Aluminum -08AN Connector Fitting B (Black Anodize Finish Only)
  • 12 Feet -08AN Black Braided Soft Line
  • x2 Barb AN Fittings
  • x4 Straight AN Fittings
  • x4 90 Degree AN Fittings
  • x1 AN O-Ring Plug
  • 6 Feet Heater Hose
  • x4 Worm Drive Hose Clamps
  • O-Rings and Hardware

OEM+ Kit Includes:

  • Billet Aluminum H-Pipe Bulkhead Adapter (Available in Raw Machined or Black Anodized Finish)
  • x2 90 Degree Heater Hose Connectors
  • 15 Feet Heater Hose
  • x8 Worm Drive Hose Clamps
  • x4 Barb AN Fittings
  • x4 90 Degree AN Fittings
  • x1 AN O-Ring Plug
  • O-Rings and Hardware

H-Pipe Bulkhead Adapter Only Includes:

  • Billet Aluminum H-Pipe Bulkhead Adapter (Available in Raw Machined or Black Anodized Finish)

Check out our video with Jason Noel explaining:

  We're excited about this new addition to our product lineup and appreciate the collaboration of our talented team in developing innovative solutions for F100 Coyote Swap enthusiasts. We'd love to hear your feedback. Happy hot rodding, and best of luck with your garage projects!
