VHX Instrument Gauge System | Chevy Pickup (1967-72)
Seven holes. Six gauges. One clean dash. The 67-72 GM dash gives you room most trucks never had and the factory cluster wastes it. Warning lamps where a tachometer belongs; a fuel gauge you stopped believing years ago. This system fills the factory seven hole bezel with six analog instruments and puts a third display above the column - an LCD message center on the PU version or an analog clock on the PA. Behind the faces are micro controlled stepper motors and solid state senders. That is why the needle lands in the same spot every time instead of wandering with the sender. Fully lit needles and backlit faces mean the dash reads the same at midnight as it does at noon. It reuses your bezel; stock or reproduction. From the driver seat the truck still looks like a 67-72 and every number on it is finally true.
Install Level: Intermediate - cluster removal and sender wiring
The instrument bezel is NOT included. A stock or reproduction bezel is required and is sold separately.
Body statement: DOES NOT FIT GMC PICKUPS.
Stock turn signal indicators are upgraded to LED.
Dakota Digital publishes a limited lifetime warranty on VHX instrumentation. Engineered and manufactured in Sioux Falls South Dakota.
1967-72 GM pickups, Blazers, and Suburbans have a simple dashboard that offers plenty of space for personalization. Making use of a seven-hole instrument bezel, this system boasts six analog instruments, along with a third LCD message center (PU) or analog clock (PA) above the column. Stock turn signals have been upgraded with LED technology, and the whole operation utilizes a stock or reproduction bezel, available separately.
Fully lit needles, backlit faces, and highly visible LCD message centers are a few of the things that you can see which set the VHX Series apart from yesterday’s traditional approach to instrumentation. A few of the features which you don’t normally see are the micro-controlled precision stepper motors, solid-state sensors for unparalleled accuracy, and user-customizable display feedback, all supported by an unrivaled limited lifetime warranty which has become the standard for Dakota Digital instrumentation systems. Completely engineered and manufactured at our facility in Sioux Falls, South Dakota, the VHX Series has completely revolutionized the instrumentation industry!
DOES NOT FIT GMC PICKUPS
Vendor: Dakota Digital
Configuration: six analog instruments in the factory seven hole bezel plus a third display above the column
Clock Style options: Digital message center (PU) or Analog clock (PA)
Style options: Black Alloy; Carbon Fiber Look; Silver Alloy
Lighting-color options: Blue; Red; White
Movements: micro controlled precision stepper motors
Senders: solid state
Lighting: fully lit needles; backlit faces; LCD message centers
Turn signal indicators: LED
Included Parts: Mounting Hardware
Bezel: not included; stock or reproduction bezel required
Warranty: limited lifetime warranty published by Dakota Digital
Listed price 1075.00 USD
Variant count: 19
No gauge face dimension or harness length is published on this listing
DOES NOT FIT GMC PICKUPS per the published listing.
The instrument bezel is not included. You reuse a stock bezel or buy a reproduction separately.
Tagged into the Chevy 1967-72 generation bucket. Ford model tags on this listing are not fitment.
