HDX Instrument Gauge System | Ford Pickup (1956)


The built-in visor above the wrap-around windshield make the one-year ’56 F-series unforgettable, and HDX instrumentation will ensure your Effie stands out in the crowd. Bolting directly to a stock or reproduction bezel (not included), this package is complete with six analog instruments and a single TFT message center. Supplied sensors and available modules allow integration with any drivetrain combination.

Available with your choice of black or silver alloy gauge-face styling, each HDX system allows the user to select independent illumination colors for the gauge readings and needles, as well as the message centers. Calibration and personal settings are manipulated with the built-in, capacitive-touch buttons, or the available Bluetooth app for Apple and Android devices. Each needle hub is black nickel plated spun-aluminum to match the buttons.

All HDX instrument systems feature dead-faced indicators (turn signals, high beam, check engine, cruise control, parking brake, plus two user-definable), and a red, settable warning light for each gauge. With our central control box, installation is greatly simplified with vehicle-harness sourced signals and supplied, solid state sending units connecting cleanly to their respective terminal.

Note: Bezel not included, shown for visual/presentation purposes.
System uses OEM or reproduction style bezel.
